Headlamp Aligner

Headlamp Aligner

ProBike
SKU:
MOT-HLA
£1,740.00 (Inc. VAT)
£1,450.00 (Ex. VAT)
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

This MoT approved beam setter allows rapid and accurate checking and aligning of motorcycle headlamps. Rail mounted with a fully adjustable head to enable fast correct positioning. Features include RS232 interface, LCD display for light intensity measurement and integral laser aligner. Supplied with its own integral 12v rechargeable battery and battery charger. Meets DVSA specifications.

Height 1770mm
Length 610mm
Minimum headlamp height 240mm
Maximum headlamp height 1500mm
Tolerance on aiming height +/- 10mm
Optical box size 250mm x 250mm x 610mm
Light intensity 0-240 lux
Focal length 500mm
Rail length 3110mm
Lens to first rail 110mm
Distance between rails 395mm
Rail recess dimension 100mm x 28mm


Note: DVSA require a 600mm clearance behind the Tester head to any wall.
